Name: Convaid Rodeo Tilt-in-Space Special Needs Stroller
SKU: 186823

The Convaid Rodeo buggy can tilt up to 45° for pressure relief and support for the upper body. It features a seat that can extend by 12.7 cm to grow with the user. There are two versions: one with built-in seating and another that allows for custom seats to be added, meeting a variety of seating needs.

The buggy's Cordura upholstery is offered in many colors, is detachable, and can be washed. It also reclines between 90 and 110 degrees for adjustable comfort. The Convaid Rodeo is designed to fold easily, making it very portable. It comes in four widths and supports users up to 77 kilograms. It is manufactured in the USA.

Features

5° to 45° of adjustable tilt

Offers relief from pressure and supports the upper body.

Lightweight & compact folding

The folding mechanism enables it to compactly fold, including the seating, making it small enough to fit in the trunk of nearly any car.

Tension adjustable back upholstery

Adjustable back straps enable personalized fitting for the lumbar and thoracic areas of the back.

Zippered pockets in upholstery

Allows for additional seat padding and support.

Upholstery Colors

Convaid's upholstery is globally recognized for its strength, resistance to wear, and superior performance. It feels good to touch and offers slight support with padded sections. The high-quality fabric used is both detachable and machine washable, ensuring user comfort.

Royal Blue

Sassy Purple

Cherry Red

Princess Pink

Panther Black

Forest Green

Standard Features

5° to 45° of Adjustable Tilt
One Piece Height Adjustable Push Handle
Seat Depth Growth of 127mm
Tool-less Upholstery Removal
Zippered Pockets in Seat Bottom Upholstery
2-Point Positioning Belt (Not available in EU)
Elevating Leg rest

One Piece Angle Adjustable Footplate
Option for solid or air tires
Quick Release Rolko Rear Tires
Single Foot Activated Wheel Lock Bar
Silver Powder Coated Frame
Made in the USA

Fitting Guide

Proper seating and positioning help maintain good posture, improving circulation, breathing, and digestion. It's important to adjust the chair to suit the user's needs. If the positioning isn't right, consider using additional accessories mentioned in the manual or consult a physical therapist. Incorrect seating can lead to health issues, so seeking advice from a physical therapist or doctor is recommended.

Step 1

Seat Back Height

- Seat back height depends on the chair type and seat width.
- Use headrest extensions for extra head support if needed.
- Measure from the seat to the top of the shoulder or upper head to find seat back height.

Step 2

Seat Width

- Seat back height depends on chair type and seat width.
- Headrest extensions can be used for additional head support.
- Measure from the seat to the top of the shoulder or upper head for seat back height.

Step 3

Seat Depth

- Seat back height depends on the type of chair and its width.
-Use headrest extensions for more height if needed for head support.
-Measure from the seat to the top of the shoulder or head to determine seat back height.

Size Chart

	RD 10	RD 12	RD 14	RD 16
Seat width	10"	12"	14"	16"
Seat depth	7" - 12"	9" - 14"	11" - 16"	13" - 18"
Seat back height	21"	22"	24"	25"
Seat to floor	20"	21"	22"	22"
Recline adjustment	90° or 110°	90° or 110°	90° or 110°	90° or 110°
Tilt adjustment	5 – 45°	5 – 45°	5 – 45°°	5 – 45°
Overall height	43"	43"	44"	45"
Overall length	30.5"	35"	35"	36"
Overall width	21"	23"	25"	27"
Folded length	33.5"	34"	34"	40"
Folded width	21"	23"	25"	27"
Folded height	17.5"	17"	18"	18"
Headrest extension	6"	8"	8"	8"
Shoulder strap height	13"-19"	15"-21"	16"-22"	18"-24"
Footplate adjustment angle one piece angle adjustable footplate	±20°	±20°	±20°	±20°”
Seat to footplate one piece angle adjustable footplate	5" - 11"	5" - 11"	7" - 13"	9" - 15"
Seat to footplate individual angle adjustable footplates	4" - 9"	4" - 9"	4" - 11"	7" - 13"
Weight capacity regular/transit	75 lbs / 66 lbs	75 lbs / 66 lbs	100 lbs / 100 lbs	170 lbs / 140 lbs
Weight of chair without front rigging	29 lbs	33 lbs	27 lbs	39 lbs
Push handle adjustment	32" - 48"	34" - 50"	35" - 52"	36" - 53"

*Reduced height when footplates are flipped

Accessories

Trays

Clear Tray

The tray provides upper extremity support and positioning to maximize upper extremity function for communication, and educational activities.

Cushions

Support - General Use Cushion

The soft foam base provides support and increased tolerance to aid in user’s comfort.

Leg and foot supports

Foot Positioners

Adjustable Velcro® straps help position the feet properly on footplates and maximizes loading contact area and proper foot alignment. Straps can be positioned to attach...

Outdoor use

Extended Headrest Cover without Windows (Canopy)

Provides extended protection from sunlight, wind and the environment. For patients that have skin sensitivity to sunlight due to clinical condition or prescription...

Bags and baskets

Utility Bag

Perfect for storing essential medical supplies and disposable items. Easily detaches from the chair, and when removed, converts to a convenient tote.

Outdoor use

Headrest Cover (Canopy)

Provides protection from sunlight, wind and the environment.

Outdoor use

Mosquito Net

The mosquito net is designed to protect the user from mosquitos and other insects.

Leg and foot supports

Calf Panel

The calf panel provides support to the lower legs to give additional support, pressure relief, and comfort. Especially helpful when the chair is in a tilted or recline...

Bags and baskets

Under Seat Storage Basket - Tilt-in-Space

The storage basket is the perfect place to stow essential medical items such as a suction device.

Paddings

Padded Elevating Legrest Cover

Leg rest extension pivot covers provide additional padding and support.

Trays

Foam Tray

The foam transit tray provides additional support when transporting the occupant in a bus or a van. It should only be used when circumstances require a tray during daily ...

Castors

Caster Lock for 2 Wide Front Tires

Provides a leverage point to elevate the front of the chair to easily go up curbs. Manufacturer installation required. Standard in EU.

Bags and baskets

Medical Necessity Storage Basket

Designed to hold large support equipment such as ventilators, external batteries, IV pumps, suction pumps, or other medical disposables. Weight capacity is 50 lbs.

Bags and baskets

Oxygen Tank Bag

The oxygen tank holder holds a size D (4”) diameter tank. Clasps hold the tank away from the chair back, and the strap at the base adjusts to stay taut when the chair is ...

Postural supports

Reducer Seat Insert

Provides proper positioning in an oversized wheelchair to maximize growth potential. The insert easily slips into the seat of the chair to reduce the seat width 2”, and...

Vests, belts and straps

Full Torso Vest

Can be used for the client with a protruding abdomen with a flexible pelvis and spine to reposition his weight back over the pelvis, or to prevent forward flexion of the ...

Attachments for medical devices

IV Pole

Convenient IV bag hanger that is height adjustable. The 7/8" diameter tubing allows for easy IV pump installation. Easily folds for compact storage and quick release

Postural supports

Adjustable Firm Lateral Trunk Support - Contoured (Swing-Away Laterals)

These firm laterals are width and height adjustable to improve alignment and promote upright trunk, as well as minimize scoliotic tendencies seen with low to moderately...

Attachments for medical devices

Mesh Side Panels

Provides additional security to prevent the child from leaning out the sides of the seat. Mesh fabric allows for increased airflow and circulation.

Abduction and adduction

Lateral Thigh Support (Adductor)

Pulls thighs together to improve hip alignment and stabilizing sitting posture. The degree of adduction can be adjusted and accommodate postural asymmetry.

Leg and foot supports

Full Padded Footbox

The full padded footbox provides comfort and safety while maintaining freedom of movement. (Requires one-piece footplate)

Cushions

Align Cushion - Lateral Pelvis/Lateral Thigh Support

Contoured edges provide lateral pelvic stability and thigh positioning to reduce lateral movement of the pelvis and improve lower extremity stability.

Brakes

Attendant Handbrake

Provides controlled and safe mobility in environments going up or downhill, and the hand brake is an addition to the wheel lock.

Head supports

Occi-Headwings

Provides sub-occipital support to help position the head midline. Provides added comfort, allows side to side head movement without obstruction, and does not block the...

Head supports

Headrest Extension

Extends back height to provide head support for taller individuals.

Arm supports

Solid Side Panels

Provide additional security to prevent the child from leaning out the sides of the seat.

Abduction and adduction

Medial Thigh Support (Abductor)

Separates thighs to improve hip alignment and stabilizing sitting posture. The degree of abduction can be adjusted and accommodate postural asymmetry.

Cushions

Position Cushion - Medial Thigh Support/Anti Thrust

Medial thigh support helps to position the legs out of abduction and into medial alignment to improve weight-bearing and maximize loading contact surface area.

Head supports

Padded Headwings

Height adjustable headwings provide soft foam lateral support for midline positioning of the head.

Postural supports

H-Harness with Padded Covers (3-Pt Positioning Belt Req)

Provides the occupant with anterior trunk support to maintain upper body trunk positioning and prevent upper body fatigue.

Vests, belts and straps

3-Point Positioning Belt

3-point positioning belt with depth adjustable crotch strap helps position the user’s pelvis properly and prevents submarining out of the chair.

Convaid Rodeo Tilt-in-Space Special Needs Stroller

Product Details

Features

5° to 45° of adjustable tilt

Lightweight & compact folding

Tension adjustable back upholstery

Zippered pockets in upholstery

Upholstery Colors

Royal Blue

Sassy Purple

Cherry Red

Princess Pink

Panther Black

Forest Green

Standard Features

Fitting Guide

Seat Back Height

Seat Width

Seat Depth

Size Chart

Accessories

Clear Tray

Support - General Use Cushion

Foot Positioners

Extended Headrest Cover without Windows (Canopy)

Utility Bag

Headrest Cover (Canopy)

Mosquito Net

Calf Panel

Under Seat Storage Basket - Tilt-in-Space

Padded Elevating Legrest Cover

Foam Tray

Caster Lock for 2 Wide Front Tires

Medical Necessity Storage Basket

Oxygen Tank Bag

Reducer Seat Insert

Full Torso Vest

IV Pole

Adjustable Firm Lateral Trunk Support - Contoured (Swing-Away Laterals)

Mesh Side Panels

Lateral Thigh Support (Adductor)

Full Padded Footbox

Align Cushion - Lateral Pelvis/Lateral Thigh Support

Attendant Handbrake

Occi-Headwings

Headrest Extension

Solid Side Panels

Medial Thigh Support (Abductor)

Position Cushion - Medial Thigh Support/Anti Thrust

Padded Headwings

H-Harness with Padded Covers (3-Pt Positioning Belt Req)

3-Point Positioning Belt

The Convaid Rodeo
